RBD series Trolley Lift High-temp Furnace (Air Pre-heat)

RBD18 series Trolley Lift High-temp Furnace (Air Pre-heat) is a kind of high precision high temperature furnace with independent air preheating equipment, which will transfer the 200 ℃ preheated air to the internal furnace equably. The heating element is MoSi2. 3 temperature areas make sure the temperature uniformity + 5 ℃. Working temperature is from 1500-1700℃.
Order Hotline:86-512-63496667-162
Enquiry

-  Product Introduction  -

RBD series Trolley Lift High-temp Furnace (Air Pre-heat)

Summary

RBD18 series Trolley Lift High-temp Furnace (Air Pre-heat) is a kind of high precision high temperature furnace with independent air preheating equipment, which will transfer the 200 ℃ preheated air to the internal furnace equably. The heating element is MoSi2. 3 temperature areas make sure the temperature uniformity + 5 ℃. Working temperature is from 1500-1700℃. All the insulation materials are ceramic fiber boards, which raw materials are imported from Japan. The thermal insulation layer use Micro-porous Insulation Board with low thermal conductivity. Temperature control precision: ±1 ℃, temperature uniformity ±5 ℃, heating fast, the fastest heating rate≤5℃/min. Widely used in electronic ceramics, powder metallurgy, machinery, building materials, refractories, special materials, new materials development and other fields.

RBD series Trolley Lift High-temp Furnace (Air Pre-heat)RBD series Trolley Lift High-temp Furnace (Air Pre-heat)

-  Technical Parameter  -

Product Model RB-17-1705240
Working Temperature 1600℃
Rated Voltage 380V±10%,50Hz±5%
Rated Power 120kw
Temp. Uniformity In the uniform temperature area 1695×520×400, 1600 ℃ ± 5 ℃
Temp.Precision ±1℃
Insulation Material Imported Ceramic fiber
Temp. Measurement B type thermocouple, 3 temperature area
Heating Element MoSi2
Safety Device over current, over temperature protection
Control Method SCR control / PID temperature control
Heating Mode Programmable control (100 step program, 10 groups of PID parameters)
Heating Rate 0-1600℃/4hr
Service Environment Atmosphere
Effective Dimension 1695×520×400
L×W×H(mm)
